商品の詳細:
お支払配送条件:
|
| 製品名: | 105C耐熱XLPE絶縁電源ケーブル | 応用: | 炉ホール、製鉄所、ボイラー室の配線 |
|---|---|---|---|
| 導体材質: | クラス 2 撚り線アニール銅、IEC 60228 | コアと断面: | 4×25mm2 |
| 定格電圧: | 0.6/1kV(うーん1.2kV) | 断熱材: | 熱安定化XLPE、公称0.9 mm |
| 温度定格: | 連続 105 ℃、短絡 250 ℃ | アウターシース: | 耐熱PVC、耐油 |
| 熱老化試験: | 135℃で7日間、70パーセント以上の引張保持率 | 設計基準: | IEC 60502-1、IEC 60216 |
| ハイライト: | Heat Resistant XLPE Insulated Power Cable,4x25mm2 Copper XLPE Insulated Power Cable,Industrial XLPE Insulated Power Cable |
||
Product Overview Standard XLPE cable is rated 90 C, and in a furnace hall, a boiler room or above a steel plant soaking pit the ambient air alone can push the conductor past that figure. This four core 25mm2 cable uses a heat stabilised XLPE compound with an antioxidant package that holds mechanical properties at 105 C continuous, so the current rating can be applied without the heavy derating factor a 90 C cable would need in the same location. The insulation is extruded to
